Flame retardant system: Using phosphorus and nitrogen as main flame retardant elements.
Main application: Electrical products, construction industry products, etc.
Flammability rating: UL 94 V0.
Glow Wire Grade: GWIT:775/3.0 and GWFI: 850/3.0.
Features: Good flowability, high rigidity, low density, low smoke, and less corrosion to the molds.
PS：We can provide you with free samples for evaluation and test, please feel free to contact us.
Product Introduction：The flammability of 5000AC can reach UL94 V-0 (1.5mm and 3.0mm), glow-wire test meets GWIT: 750/3.0 and GWFI 850/3.0. 5000AC has UL certificate and meets the requirements of RoHS, SVHC, PFOS&PFOA, 17P, Halogen-free, and PAHs, etc. 5000AC has the characteristics of good flowability, high rigidity, low density, low smoke, and less corrosion to the molds.
HFFR PP
Application: Electronic products, etc.
Multiple certification guarantee
Reach Certification,
RoHs Certification,
ISO9001:2015 Certification,
IATF16949:2016 Certification, etc.
UL94 V0
Flame retardant performance: Phosphorus and nitrogen as the flame retardant elements
Temperature: GWIT 750/3.0 and GWFI 850/3.0
Characteristic: Good flowability, high rigidity, low density, low smoke and less corrosion to the molds.
| Specification | Test Method | Unit | High rigidity halogen-free flame retardant PP |
| Density | ASTM D792 | g/cm3 | 1.12 |
| Melt Flow Index (230℃/2.16kg) | ASTM D1238 | g/10min | 16 |
| Mold Shrinkage | ASTM D955-08 | % | 0.92(vertical) |
| 1.2(horizontal) | |||
| Tensile Strength | ASTM D638 | MPa | 20 |
| Elongation at Break | ASTM D638 | % | 55 |
| Flexural Strength | ASTM D790 | MPa | 28 |
| Flexural Modulus | ASTM D790 | MPa | 2000 |
| Izod Notched Impact Strength | ASTM D256 | J/m | 20 |
| Flammability | UL 94 | 1.5mm | V-0 |
| 3.0mm | V-0 | ||
| 3.0mm | 5VA | ||
| Glow Wire | IEC 60695-2-13 | GWIT:750/3.0 | Pass |
| IEC 60695-2-12 | GWFI:850/3.0 | Pass |
Remark: The above laboratory test data are just for reference only; it's not a basis for quality assurance.
Electrical enclosure
Heater
Coil bobbin
