Flame retardant system: Using bromine and antimony as flame-retardant elements.
Main application: Aroma diffuser shell, street light switch box, etc.
Flammability rating: UL 94 V2
Glow Wire Grade: GWFI:850/3.0
Features: Good weather-resistant, low smoke, less corrosion to the molds, low density of finished products.
PS：We can provide you with free samples for evaluation and test, please feel free to contact us
Products Introduction: 5003X1(f1), whose flammability reaches UL 94 V-2（1.5mm and 3.0mm）and glow-wire test passes GWFI:850/3.0. SAMATTM 5003X1(f1) has UL certificate and meet the requirements of RoHS、SVHC、PFOS&PFOA、17P、PAHs, etc. SAMATTM 5003X1(f1) has the characteristics of good weather-resistant, low smoke, less corrosion to the molds, low density of finished products.
HFFR PP
Application: Aroma diffuser shell, street light switch box, etc.
Multiple certification guarantee
Reach Certification,
RoHs Certification,
ISO9001:2015 Certification,
IATF16949:2016 Certification, etc.
UL94 V2
Flame retardant performance: Using bromine and antimony as flame-retardant elements.
Temperature: GWFI:850/3.0
Characteristic: Halogen-free, environment-friendly, good flame retardant property, without precipitation, good processing flowability, excellent UV resistance.
| Specification | Test Method | Unit | Weather-resistant flame retardant PP |
| Density | ASTM D792 | g/cm3 | 0.98 |
| Melt Flow Index (230℃/2.16kg) | ASTM D1238 | g/10min | 15 |
| Mold Shrinkage | ASTM D955-08 | % | 1.3-1.7 |
| Tensile Strength | ASTM D638 | MPa | 32 |
| Elongation at Break | ASTM D638 | % | 100 |
| Flexural Strength | ASTM D790 | MPa | 36 |
| Flexural Modulus | ASTM D790 | MPa | 1300 |
| Izod Notched Impact Strength(23℃) | ASTM D256 | J/m | 32 |
| Heat Deflection Temperature(0.455MPa) | ASTM D648 | ℃ | 110 |
| Flammability | UL 94 | 1.5mm | V-2 |
| 3.0mm | V-2 | ||
| Glow-Wire | IEC 60695-2-12 | GWFI:850/3.0 | Pass |
Remark: The above laboratory test data are just for reference only; it's not a basis for quality assurance.
Electric blanket connector
Automobile switchboard
Automobile switchboard
Dear customers, no need to worry about your products colors, POLYROCKS has professional colour matching department, providing free colour matching service. Any colour requirements, kindly please contact us by email: sales@polyrocks.com.
POLYROCKS focus on provide prompt pre/after-sales service, we have professional injection molding engineers and technical service engineers to provide accurate information and timely service. Any questions or needs, you are welcome to contact us by email: sales@polyrocks.com.
Any purchasing questions, welcome to contact our customer service, helps will be provided by them.
